Construction:
Tube: Oil resistant synthetic rubber
Reinforcement: Single layer of high-tensile steel wire braided
Cover: Oil and weather resistant synthetic rubber
Temperature : -40℃ ～ +100℃
Application: Petroleum based hydraulic fluid, gasoline, water, diesel fuels, lubricating oils, glycol, mineral oils, and more
PILOT HOSE
Hose ID | Hose O.D. | Working Pressure | Min. Burst | Min. Bend | Length | Weight | |||||
In. | mm | In. | mm | psi | MPa | psi | MPa | In. | mm | m | Kg/m |
1/4 | 6.4 | 0.48 | 12.1 | 1815 | 12.5 | 7250 | 50.0 | 1.18 | 30.0 | 50/100 | 0.19 |
5/16 | 8.0 | 0.54 | 13.7 | 1815 | 12.5 | 7250 | 50.0 | 1.57 | 40.0 | 50/100 | 0.20 |
3/8 | 9.5 | 0.63 | 15.9 | 1815 | 12.5 | 7250 | 50.0 | 1.97 | 50.0 | 50/100 | 0.25 |
1/2 | 12.7 | 0.76 | 19.2 | 1815 | 12.5 | 7250 | 50.0 | 2.36 | 60.0 | 50/100 | 0.35 |
