SAE 100 R8 / DIN EN855 (Steel)

SAE 100 R8

Construction:

Tube: Thermoplastic Elastomer

Reinforcement: double layers braided of steel wire

Cover: PU(polyurethane)

Temperature: -40°C to +100°C

Application: High Pressure Hydraulic Lines 150 to 450 bar compact, high pressure, light weight and low change in length. Suitable for hydraulic application with increased resistance to abrasion for use with petroleum, synthetic or water based fluids in Hydraulic system.

E-mail Send Message

Detailed

SAE 100 R8 / DIN EN855 (Steel)

Hose ID		Hose O.D.		Working Pressure		Burst Pressure		Bend Radius
In.	mm	In.	mm	Bar	Psi	Bar	Psi	mm	In.
5/32	4.0	0.39	10.5	450	6500	1800	26000	80	3.1
3/16	5.0	0.41	11.7	450	6500	1800	26000	80	3.1
1/4	6.4	0.50	13.5	430	6250	1720	25000	100	4.0
5/16	8.0	0.57	15.2	380	5500	1520	22000	110	4.3
3/8	10.0	0.67	17.5	330	4800	1320	19200	130	5.0
1/2	12.7	0.83	20.3	270	3900	1080	15600	180	7.0
5/8	16.0	1.00	25.5	250	3625	840	12000	205	8.0
3/4	19.0	1.10	29.5	215	3120	700	10000	255	10.0
1	25.0	1.42	39.0	165	2400	600	8800	305	12.0
