Construction:
Tube: Nylon
Reinforcement: high tensile steel wire
Cover: Polyurethane
Temperature: -40°C to +100°C
Color: Red
Application: Refueling hose specially designed for conveying compressed natural gas.
Dissipates static build-up.
Hyrotech striving hard for every customer’s satisfaction. Welcome customers from all over the world to contact us.
Construction:
Tube: Nylon
Reinforcement: high tensile steel wire
Cover: Polyurethane
Temperature: -40°C to +100°C
Color: Red
Application: Refueling hose specially designed for conveying compressed natural gas.
Dissipates static build-up.
CNG Hose
Hose ID | Hose O.D. | Working | Burst | MIN.Bend | |||||
In. | mm | In. | mm | Bar | Psi | Bar | Psi | mm | In. |
1/4 | 6.4 | 0.54 | 13.7 | 350 | 5000 | 1400 | 20000 | 50.8 | 2.0 |
5/16 | 8.0 | 0.60 | 15.2 | 350 | 5000 | 1400 | 20000 | 55.0 | 2.2 |
3/8 | 9.6 | 0.69 | 17.5 | 350 | 5000 | 1400 | 20000 | 76.2 | 3.0 |
1/2 | 12.8 | 0.83 | 21.1 | 350 | 5000 | 1400 | 20000 | 101.3 | 4.0 |
3/4 | 19.0 | 1.15 | 29.2 | 350 | 5000 | 1400 | 20000 | 191.0 | 7.5 |
1 | 25.0 | 1.44 | 36.6 | 350 | 5000 | 1400 | 20000 | 280.0 | 11.0 |
