Sewer Jetting hose

Construction:

Tube: thermoplastic elastomer

Reinforcement: 2 layers high tensile synthetic fiber braided

Cover: abrasion resistant polyurethane

Temperature: -40°C to +70°C

Length: 200FT,333FT, 400FT,500FT,600FT,800FT

Color: Black, Orange,Green,Blue,Red

Application: Compact Sewer cleaning vehicles and lateral Sewer line cleaning equipments. Heavy duty construction for optimum cut and wear resistance. Bonded tube and cover available in long lengths with a special cover, resistant to microbiological degradation. High pressure performance and flexible hose for cleaning smaller sized sewer ducts.

E-mail Send Message

Detailed

Sewer Jetting Hose

SEWER JETTING HOSE(ES-SJ-I-2500PSI)
Hose ID		Hose O.D.		Working Pressure		Burst Pressure		MIN.Bend Radius
In.	mm	In.	mm	Bar	Psi	Bar	Psi	mm
3/8	10.0	0.69	18.0	173	2500	431	6250	60
1/2	13.0	0.80	22.1	173	2500	431	6250	75
5/8	16.0	1.00	27.2	173	2500	431	6250	103
3/4	19.0	1.15	32.2	173	2500	431	6250	120
1	25.4	1.50	38.7	173	2500	431	6250	155
1 1/4	32.8	1.87	46.6	173	2500	431	6250	240

SEWER JETTING HOSE(ES-SJ-II-3000PSI)
Hose ID		Hose O.D.		Working Pressure		Burst Pressure		MIN.Bend Radius
In.	mm	In.	mm	Bar	Psi	Bar	Psi	mm
3/8	10.0	0.69	18.0	210	3000	518	7500	60
1/2	12.7	0.80	22.3	210	3000	518	7500	75
5/8	16.0	1.00	27.2	210	3000	518	7500	105
3/4	19.0	1.15	32.2	210	3000	518	7500	120
1	25.4	1.50	38.7	210	3000	518	7500	155

SEWER JETTING HOSE(ES-SJ-III-4000PSI)
Hose ID		Hose O.D.		Working Pressure		Burst Pressure		MIN.Bend Radius
In.	mm	In.	mm	Bar	Psi	Bar	Psi	mm
1/4	6.3	0.50	12.7	280	4000	690	10000	60
3/8	10.0	0.67	18.0	280	4000	690	10000	100
1/2	12.7	0.80	22.5	280	4000	690	10000	120
5/8	16.0	1.00	27.3	280	4000	690	10000	145
3/4	19.0	1.15	32.4	280	4000	690	10000	165
1	25.4	1.50	38.9	280	4000	690	10000	200
