Paint Spray hose

Construction:

Tube: Nylon

Reinforcement: one or two layers high-tensile steel wire/2 layers braided of fiber

Cover: polyurethane

Temperature: -40°C to +100°C

Length: 33FT,50FT,67FT,100FT

Color: Black,Blue,Red,Yellow

Application: Very High pressure Airless paint spray systems for 200 to 700 Bar. Suitable for applications requiring chemical resistance to solvents and aggressive fluids,use for painting spray machine

E-mail Send Message

Detailed

Paint Spray Hose

PAINT SPRAY HOSE(ES-PS-I)
Hose ID		Hose O.D.		Working Pressure		Burst Pressure		MIN.Bend Radius
In.	mm	In.	mm	Bar	Psi	Bar	Psi	mm	In.
1/4	6.3	0.50	12.8	250	3625	900	13050	45	1.77
5/16	8.0	0.57	14.5	250	3625	800	11600	50	1.97
3/8	10.0	0.67	17.0	200	2900	750	10875	60	2.36
1/2	12.7	0.87	22.0	200	2900	700	10150	80	3.15

PAINT SPRAY HOSE(ES-PS-II)
Hose ID		Hose O.D.		Working Pressure		Burst Pressure		MIN.Bend Radius
In.	mm	In.	mm	Bar	Psi	Bar	Psi	mm	In.
1/4	6.3	0.47	12.0	350	5075	1050	15225	40	1.77
5/16	8.0	0.52	13.2	350	5075	1050	15225	75	2.95
3/8	10.0	0.60	15.2	280	4060	1000	14500	80	3.15
1/2	12.7	0.75	19.0	250	3625	900	13050	110	4.33

PAINT SPRAY HOSE(ES-PS-III)
Hose ID		Hose O.D.		Working Pressure		Burst Pressure		MIN.Bend Radius
In.	mm	In.	mm	Bar	Psi	Bar	Psi	mm	In.
1/4	6.4	0.53	13.5	800	7250	1200	17400	65	2.56
5/16	8.0	0.61	15.5	480	6960	1200	17400	95	3.74
3/8	10.0	0.69	17.5	450	6525	1200	17400	110	4.33
1/2	12.7	0.87	22.0	410	6000	1100	15950	130	5.19
