SAE 100R7/DIN EN855 (Steel)

SAE 100 R7

Construction:

Tube: Thermoplastic Elastomer

Reinforcement: single braid of steel wire

Cover: PU(polyurethane)

Temperature: -40°C to +100°C

Application: Medium Pressure Hydraulic Lines 100 to 350 bar. Suitable for hydraulic application with increased resistance to abrasion for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agricultural machinery, Earth-moving, etc

E-mail Send Message

Detailed

SAE 100R7/DIN EN855 (Steel)

Hose ID		Hose O.D.		Working Pressure		Burst Pressure		Bend Radius
In.	mm	In.	mm	Bar	Psi	Bar	Psi	mm	In.
5/32	4.0	0.34	9.0	350	5000	1400	20000	25	1.0
3/16	5.0	0.38	9.7	350	5000	1200	17400	30	1.2
1/4	6.3	0.45	12.0	300	4350	1100	15600	40	1.6
5/16	8.0	0.52	13.2	240	3500	960	14000	50	2.0
3/8	10.0	0.60	15.2	225	3265	880	12800	60	2.4
1/2	12.7	0.75	18.5	190	2750	700	10000	75	3.0
5/8	16.0	0.87	24.0	150	2175	560	8000	110	4.3
3/4	19.0	1.02	28.0	130	1890	460	6400	150	6.0
1	25.0	1.30	37.0	105	1525	400	5800	230	9.1
