Construction:
Tube: Oil resistant synthetic rubber
Reinforcement: Two layers high fiber braids
Cover: Oil and weather resistant synthetic rubber
Temperature: -40°C to +100°C
Application: Petroleum based hydraulic fluid, gasoline, water, lubricating oils, glycol, mineral oils, and more.
DIN EN854 3TE
Size | Hose ID | Hose O.D. | Max Working Pressure | Min Burst | Min Bend | Weight | |||
In. | mm | mm | mm | Bar | Psi | Bar | Psi | mm | kg/m |
3/16 | 5 | 5±0.2 | 12.8±0.3 | 160 | 2320 | 640 | 9280 | 40 | 0.16 |
1/4 | 6 | 6.2±0.2 | 14.5±0.3 | 145 | 2103 | 580 | 8410 | 45 | 0.19 |
5/16 | 8 | 8±0.2 | 17±0.3 | 130 | 1885 | 520 | 7540 | 55 | 0.24 |
3/8 | 10 | 9.8±0.2 | 18±0.3 | 110 | 1595 | 440 | 6380 | 70 | 0.27 |
1/2 | 12.5 | 12.5±0.2 | 21.8±0.3 | 93 | 1349 | 372 | 5394 | 85 | 0.34 |
5/8 | 16 | 16±0.2 | 26±0.3 | 80 | 1160 | 320 | 4640 | 105 | 0.43 |
3/4 | 19 | 19±0.2 | 29±0.3 | 70 | 1015 | 280 | 4060 | 130 | 0.50 |
1 | 25 | 25±0.2 | 36±0.3 | 55 | 798 | 220 | 3190 | 150 | 0.67 |
1-1/4 | 32 | 32±0.2 | 42.3±0.3 | 45 | 6539 | 180 | 2610 | 190 | 0.83 |
