Construction:
Tube: Oil resistant synthetic rubber
Reinforcement: One high-strength fiber braid
Cover: Oil and weather resistant synthetic rubber
Temperature: -40°C to +100°C
Application: Petroleum based hydraulic fluid, gasoline, water, lubricating oils, glycol, mineral oils, and more.
DIN EN854 1TE
Size | Hose ID | Hose O.D. | Max Working Pressure | Min Burst | Min Bend | Weight | |||
In. | mm | mm | mm | Bar | Psi | Bar | Psi | mm | kg/m |
3/16 | 5 | 5±0.2 | 11.5±0.3 | 25 | 363 | 100 | 1450 | 35 | 0.15 |
1/4 | 6 | 6.2±0.2 | 13±0.3 | 25 | 363 | 100 | 1450 | 45 | 0.15 |
5/16 | 8 | 8±0.2 | 14.2±0.3 | 20 | 290 | 80 | 1160 | 65 | 0.17 |
3/8 | 10 | 9.8±0.2 | 15.9±0.3 | 20 | 290 | 80 | 1160 | 75 | 0.17 |
1/2 | 12.5 | 12.5±0.2 | 19±0.3 | 16 | 232 | 64 | 928 | 90 | 0.27 |
5/8 | 16 | 16±0.2 | 23±0.3 | 16 | 232 | 64 | 928 | 115 | 0.31 |
3/4 | 19 | 19±0.2 | 26.6±0.3 | 12 | 174 | 48 | 696 | 135 | 0.44 |
1 | 25 | 25±0.2 | 33±0.3 | 12 | 174 | 48 | 696 | 165 | 0.55 |
