Construction:
Tube: Oil resistant synthetic rubber
Reinforcement: One high-strength fiber braid
Cover: Oil and weather resistant synthetic rubber
Temperature: -40°C to +100°C
Application: Petroleum based hydraulic fluid,gasoline, water, lubricating oils, glycol, mineral oils, and more
DIN EN854 2TE
Size | Hose ID | Hose O.D. | Max Working Pressure | Min Burst | Min Bend | Weight | |||
In. | mm | mm | mm | Bar | Psi | Bar | Psi | mm | kg/m |
3/16 | 5 | 5±0.2 | 11.5±0.3 | 80 | 1160 | 320 | 4640 | 35 | 0.16 |
1/4 | 6 | 6.2±0.2 | 13±0.3 | 75 | 1088 | 300 | 4325 | 40 | 0.19 |
5/16 | 8 | 8±0.2 | 14.2±0.3 | 68 | 986 | 272 | 3944 | 50 | 0.24 |
3/8 | 10 | 9.8±0.2 | 16.2±0.3 | 63 | 914 | 252 | 3656 | 60 | 0.27 |
1/2 | 12.5 | 12.5±0.2 | 19.8±0.3 | 58 | 841 | 232 | 3364 | 70 | 0.34 |
5/8 | 16 | 16±0.2 | 23±0.3 | 50 | 725 | 200 | 2900 | 90 | 0.43 |
3/4 | 19 | 19±0.2 | 27±0.3 | 45 | 653 | 180 | 2612 | 110 | 0.50 |
1 | 25 | 25±0.2 | 33±0.3 | 40 | 580 | 160 | 2320 | 130 | 0.67 |
1-1/4 | 32 | 30±0.2 | 42.3±0.3 | 35 | 507 | 140 | 2028 | 150 | 0.83 |
