HT-91C6H Workshop hose crimping machine
Hyrotech striving hard for every customer’s satisfaction. Welcome customers from all over the world to contact us.
HT-91C6H Workshop hose crimping machine
HT-91C6H Workshop hose crimping machine
New integrated valve group,better stability
Function: manual,semi-automatic and automatic.
Available for quick change dies
Resin gasket between dies protect the machine from debris dropping
D(mm) | 14 | 16 | 19 | 22 | 26 | 30 | 34 | 39 | 45 | 51 | 57 | 63 |
L(mm) | 65 | 65 | 65 | 65 | 65 | 65 | 70 | 70 | 80 | 80 | 80 | 80 |
Technical data | |
Model | HT-91C6H |
Crimping range | 1/4”-2”4sp |
Voltage | 380V/3ph or customized |
Motor power | 3kw |
Opening without dies | Φ122mm |
Dies opening | ≥28mm |
No.of die sets | 12 sets |
Pressure systematic | 30Mpa |
Noise level | ≤69dB |
Oil tank | 65L |
Machine weight | 310kgs |
Package weight | 380kgs |
Machine dimension | 800*630*1376 (mm) |
Package dimension | 880*720*1590 (mm) |
