Construction:
Tube: black, smooth synthetic rubber, super-air and oil mist resistance
Reinforcement: two high tensile steel wire braid
Cover: yellow or black,synthetic rubber, heat, corrosion and flame resistance rubber
Temperature range: -40°C to +100°C
High pressure compressed air hose
Hose ID | Hose O.D. | Working Pressure | Min. Burst Pressure | Min. Bend Radius | Weight | |||||
In. | mm | In. | mm | bar | psi | bar | psi | mm | Kg/m | lbs/ft |
1/2 | 13 | 0.91 | 23 | 40 | 5800 | 160 | 23200 | 60 | 0.58 | 0.39 |
3/4 | 19 | 1.16 | 29.5 | 40 | 5800 | 160 | 23200 | 100 | 0.84 | 0.57 |
1 | 25 | 1.48 | 37.7 | 40 | 5800 | 160 | 23200 | 120 | 1.28 | 0.86 |
1 1/4 | 32 | 1.85 | 47 | 40 | 5800 | 160 | 23200 | 160 | 2.01 | 1.36 |
1 1/2 | 38 | 2.11 | 53.6 | 40 | 5800 | 160 | 23200 | 180 | 2.35 | 1.59 |
2 | 51 | 2.58 | 65.6 | 40 | 5800 | 160 | 23200 | 250 | 2.75 | 1.86 |
2 1/2 | 64 | 3.07 | 78 | 40 | 5800 | 160 | 23200 | 310 | 3.56 | 2.41 |
3 | 76 | 3.70 | 94 | 40 | 5800 | 160 | 23200 | 380 | 4.03 | 2.72 |
4 | 102 | 4.96 | 126 | 40 | 5800 | 160 | 23200 | 500 | 7.62 | 5.15 |
