Construction:
Tube: oil, gasoline and diesel resistant smooth black nitrile rubber
Reinforcement: one high tensile steel wire braid
Cover: flame,oil,fuel, abrasion,ozone and weather resistant synthetic rubber
Conductivity: R < 102 Ω
Temperature:-30°C to +55°C
Application: for all types of gasoline dispensing applications
Fuel Dispenser Hose
I.D | O.D(approx.) | W.P | B.P | M.B.R | Length | Net Weight | |||||
inch | mm | inch | mm | bar | psi | bar | psi | mm | m | Kg/m | lbs/ft |
1/4 | 6 | 0.63 | 16 | 16 | 230 | 48 | 690 | 50 | 15/25/50 | 0.33 | 0.22 |
3/8 | 10 | 0.77 | 19.5 | 16 | 230 | 48 | 690 | 55 | 15/25/50 | 0.42 | 0.29 |
1/2 | 13 | 0.94 | 24 | 16 | 230 | 48 | 690 | 60 | 15/25/50 | 0.56 | 0.38 |
5/8 | 16 | 1.01 | 25.6 | 16 | 230 | 48 | 690 | 80 | 15/25/50 | 0.57 | 0.39 |
3/4 | 19 | 1.13 | 28.8 | 16 | 230 | 48 | 690 | 100 | 15/25/50 | 0.67 | 0.45 |
1 | 25 | 1.38 | 35 | 16 | 230 | 48 | 690 | 150 | 15/25/50 | 0.83 | 0.56 |
1 1/4 | 32 | 1.73 | 44 | 16 | 230 | 48 | 690 | 175 | 15/25/50 | 1.25 | 0.84 |
1 1/2 | 38 | 1.97 | 50 | 16 | 230 | 48 | 690 | 225 | 15/25/50 | 1.45 | 0.98 |
