CHARACTERISTICS & APPLICATION:
Being light in weight, with good resistance to the hard weather conditions and minus pressure, and small bending radius, this hose is used for drawing and conveying water, oil, grain and powder in factories, agriculture and civil engineerings. It is theexcellent substitutes for rubber hoses and metal pipes.
PVC Suction Hose
SPECIFICATIONS OF PVC SUCTION HOSE | ||||||||
Item No. | British Measurement | Metric Measurement | W.P | B.P | Length | Weight | Packing Measurement | |
Inside Dia. | Wall Thickness | |||||||
inch | (mm) | (mm) | (bar) | (bar) | (m) | (kg) | D(mm)×H(mm) | |
025 | 1 | 25 | 3.5 | 8 | 32 | ≤50 | 12.8 | 730×220 |
032 | 1-1/4 | 32 | 4 | 8 | 30 | ≤50 | 18.3 | 800×200 |
038 | 1-1/2 | 38 | 4 | 8 | 26 | ≤50 | 21.4 | 830×250 |
051 | 2 | 51 | 4.3 | 7 | 24 | ≤50 | 27.5 | 1000×300 |
064 | 2-1/2 | 64 | 4.5 | 6 | 20 | ≤50 | 39.2 | 1200×310 |
076 | 3 | 76 | 5 | 5 | 20 | ≤50 | 51.5 | 1400×330 |
102 | 4 | 102 | 5.5 | 5 | 16 | ≤50 | 75.2 | 1800×450 |
127 | 5 | 127 | 5.7 | 4 | 13 | ≤50 | 96.2 | 2000×470 |
152 | 6 | 152 | 7 | 4 | 12 | ≤50 | 137.6 | 2200×500 |
