How to Choose the Right Hydraulic Hose Standards?

What are the standards for hydraulic hoses?

There are three main global standards for hydraulic hoses: DIN, SAE, and ISO.
1.SAE Standard (Society of Automotive Engineers)

Defined by the SAE J517 guideline, this standard governs the entire hydraulic hose system. It maintains a dominant global presence, particularly within the North American market and for equipment manufactured by U.S.-based OEMs.

2.EN Standards (European Norms)

Derived from the German DIN technical framework, EN standards are the benchmark for the European market. Their nomenclature is highly intuitive, allowing users to identify the number of steel wire reinforcement layers directly from the model designation.

3.ISO Standards (International Organization for Standardization)

Established to harmonize global technical requirements and minimize trade barriers, ISO standards integrate the core strengths of both SAE and EN. While they show significant overlap with existing systems, they also introduce unique international innovations.

How to Choose the Appropriate Hydraulic Hose Standard?

In hydraulic system maintenance and design, choosing the appropriate standard is crucial to ensuring system pressure matching, flow stability, and component compatibility. The following are selection recommendations based on technical attributes:

1. Based on Original Equipment Manufacturer (OEM) Technical Specifications

• SAE Standard (J517): If the main equipment is a North American brand or follows North American design standards, SAE J517 must be selected. Its pressure rating and dimensional tolerances are set according to the American system.

• EN Standard (based on DIN): If the equipment originates from Europe or adopts the German industrial standard system, EN 853 (steel wire braid) or EN 856 (steel wire spiral) are the standard choices. Their reinforcement layer design and tolerance range have the highest compatibility with European-made hydraulic components.

• ISO Standard: As standards of the International Organization for Standardization, ISO 1436, ISO 3862, etc., have become the benchmark for cross-border trade and global equipment maintenance, possessing the widest interchangeability.

2. Based on Reinforcement Layer Naming Logic

• EN Standard: Highly recognizable. For example, 1SN/2SN represents single/double layer steel wire braiding, and 4SP/4SH represents four layers of steel wire winding. If you need to quickly identify the reinforced structure by model number, the EN standard is the most intuitive.

• SAE Standard: Classified by the 100R series (e.g., 100R1, 100R2). It not only specifies the structure but also details the material properties and temperature ratings for each model.

3. Classification by Pressure Method (Constant Pressure vs. Stepped Pressure)

• Traditional SAE/EN Standards: Pressure ratings typically decrease with increasing pipe diameter. That is, for hoses of the same model, the larger the pipe diameter, the lower the rated working pressure.

• ISO 18752 Standard: Introduced the concept of constant pressure rating. Under this standard, regardless of changes in hose dash size, the rated pressure (e.g., 21MPa, 35MPa, 42MPa) remains consistent. This greatly simplifies pressure calculations and selection for complex systems.
